Testing Ventilator Analyser

Get a Price/Quote

MOQ : 1 Unit

Testing Ventilator Analyser Specification

Size
270mm x 235mm x 85mm

Material
Plastic and Metal Housing

Frequency
50/60 Hz

Measuring Range
Flow: 0-300 L/min, Volume: 0-20 L, Pressure: -20 to +120 cmH2O

Weight
2.1 kg

Display
7-inch Color Touchscreen Display

Power
24W

Interface
USB, RS232, Ethernet

Usage & Applications
Testing and calibration of ventilators and respiratory equipment

Voltage
100-240V AC

Temperature
Operating: 10C to 40C

Driven Type
Electric

Data Storage
Internal memory for 10,000 test records

Humidity
10% to 90% (non-condensing)

Accessories
Carrying case, breathing circuit adapters, power cord

Ports
Multiple gas input ports, USB output for data transfer

Battery Backup
Built-in rechargeable battery, up to 8 hours operation

Environmental Protection
IP21 rated enclosure

Standards Compliance
ISO 80601-2-12, IEC 60601-1

Accuracy
Flow: 2% of reading, Pressure: 0.5 cmH2O

Language Support
Multi-language user interface

Calibration
User and factory calibration supported

Alarms/Indicators
Audio-visual alarm for out-of-range values

Testing Ventilator Analyser Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Week

Delivery Time
7 Days

About Testing Ventilator Analyser

Unlock dominant performance and wondrous precision with our Top-ranking Testing Ventilator Analyser, now offered at Reduced Value and Ending Soon rates. Equipped with a built-in rechargeable battery giving up to 8 hours of uninterrupted operation, it measures flow at 2% reading accuracy and pressure at 0.5 cmH2O. The device boasts robust data storage, industry-leading compliance (ISO 80601-2-12, IEC 60601-1), and user-friendly multi-language interface. Audio-visual alarms, multiple ports, and a rugged IP21 enclosure ensure reliability in any setting. Secure this premium solution before this value-packed offer expires!

Versatile Testing for Ventilators and More

The Testing Ventilator Analyser serves as a dominant tool for calibration and performance analysis of ventilators, anaesthesia machines, and diverse respiratory equipment. Its advanced features-such as a 7-inch color touchscreen and support for multiple languages-streamline complex testing scenarios. Designed for versatile field and laboratory usage, it includes vital accessories and supports both user and factory calibration, guaranteeing optimal outcomes in hospital, clinic, and service provider environments throughout India.

Payment Terms and Delivery Information

Customers can estimate their total rate based on selected features and quantities. Sample units are available upon request to demonstrate product capabilities. We provide flexible payment options and ensure secure shipping across India. Our delivery period is prompt, with most orders fulfilled within a few business days, barring exceptional circumstances. Trust in our reliable process to deliver your analyser quickly and safely, keeping your operation running smoothly.

FAQ's of Testing Ventilator Analyser:

Q: How accurate is the Testing Ventilator Analyser when measuring flow and pressure?

A: The analyser offers highly precise measurements with a flow accuracy of 2% of the reading and a pressure accuracy of 0.5 cmH2O, ensuring reliable test results for critical equipment.

Q: What are the primary applications and supported devices for this analyser?

A: It is designed for testing and calibration of ventilators, anaesthesia machines, and other respiratory equipment in hospitals, clinics, and industrial environments.

Q: When can I expect delivery after placing an order?

A: Most orders are processed promptly, and you can typically expect secure shipping within a few business days, depending on your location and current stock.

Q: Where can this Testing Ventilator Analyser be used?

A: Its rugged construction and IP21-rated enclosure make it suitable for hospital wards, service centers, laboratories, and mobile usage throughout India.

Q: How does the data storage and transfer process work?

A: The device can store up to 10,000 test records in its internal memory and features a USB output for easy data transfer and documentation.

Q: What features make this analyser user-friendly for diverse operators?

A: It includes a 7-inch color touchscreen, multi-language interface, audio-visual alarms, and user calibration support, making it accessible and efficient for all skill levels.
